$0.90 – $16.90
Brand: ClampSuitable for hand or hydraulic swaging. Extruded copper for use with stainless steel wire. Nickel plated to aesthetically blend with stainless steel wire. Not suitable for galvanised wire. Suitable for use on metric and imperial wire.
BLA Code | PackQty | Rope/WireDia. mm | Rope/WireDia. in | Die Cavity mm |
---|---|---|---|---|
162148 | 1 | 1.5 | 1/16 | 4.9 |
162150 | 1 | 2 | 5/64 | 4.9 |
162150P | 6 | 2 | 5/64 | 4.9 |
162152 | 1 | 2.5 | 3/32 | 6 |
162152P | 6 | 2.5 | 3/32 | 6 |
162154 | 1 | 3 | 1/8 | 7.3 |
162154P | 6 | 3 | 1/8 | 7.3 |
162156 | 1 | 4 | 5/32 | 9.1 |
162156P | 4 | 4 | 5/32 | 9.1 |
162158 | 1 | 5 | 3/16 | 10.9 |
162160 | 1 | 6.4 | 1/4 | 12.7 |
162164 | 1 | 8 | 5/16 | 17 |
‘P’ – Denotes packaged item
